ENGLISH

DisplayPort Connection

Transmits digital video and audio signals from your PC to the

monitor. Connect the monitor to your PC using the display

port cable as shown in the illustration below.

DP OUT

NOTE

• There may be no video or audio output depending on the

DP (DisplayPort) version of the PC.

• Make sure to use the supplied DisplayPort cable of

the product. Otherwise, this may cause the device to

malfunction.

• For using Mini DP to DP (Mini DisplayPort to DisplayPort)

cable, it is recommended that you use DisplayPort 1.2

cable.

Thunderbolt Connection

You can connect your high-resolution display or high-

performance data device to the monitor via a Thunderbolt

( ) port. Connect your external device to the monitor using

the Thunderbolt cable as illustrated below.

34UM88, 34UB88

(sold separately)

DP OUT

NOTE

• The maximum data transmission rate of each port is

20 Gb/s.

• Make sure to use a Thunderbolt ( ) certified cable.

Otherwise, this may cause the device to malfunction.

• Thunderbolt ( ) is supported in such environments as

Windows 7, Windows 8.1, Windows 10, and Mac product.

• In accordance with Mac products may not support the

recommended resolution or the some features.

• The ability to set up dual monitors using the Thunderbolt

( ) and daisy-chaining technology depends on the

performance of your video card.

Questions and Answers:

Need help?

Do you have a question about the LG 34UM88C-P and is the answer not in the manual?

LG 34UM88C-P Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.2325 x 0.2325 mm
Screen shape	Flat
Display diagonal	34 \
Display technology	LED
Native aspect ratio	21:9
Peak luminance ratio	66 %
sRGB coverage (typical)	99 %
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display brightness (peak)	- cd/m²
Digital vertical frequency	56 - 61 Hz
Digital horizontal frequency	30 - 90 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
Dynamic contrast ratio marketing name	Mega Contrast
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Audio system	Maxx
On/off switch	-
Mercury content	0 mg
AC input voltage	100 - 240 V
Power consumption (off)	0.3 W
Annual energy consumption	79 kWh
Power consumption (standby)	1.2 W
Power consumption (typical)	65 W
RMS rated power	14 W
Certification	UL (cUL), TUV, FCC-B, CE, ErP, Windows, DisplayPort
Product color	Black
Package depth	207 mm
Package width	978 mm
Package height	522 mm
Package weight	11300 g
Package material	Expanded polystyrene (EPS)
Cables included	AC, DisplayPort, HDMI
