66
Serial Communication Function
16. Key (Command: mc)
 Sends a key code of the IR remote
control.
Transmission
[m][c][][Set ID][][Data][Cr]
Data Key Code: see 67 page .
(* Transmitted in hexadecimal code)
Ack
[c][] [Set ID][][OK][Data][x]
Data Key Code
20. Monitor Out (Command: nr)
 Select either RGB1 or RGB2 input as an
output of the RGB OUT port.
Transmission
[n][r][][Set ID][][Data][Cr]
Data 00 : RGB 1 01 : RGB 2
02: Auto
Ack
[r][] [Set ID][][OK][Data][x]
Data 00 : RGB 1 01 : RGB 2
02: Auto
18. Mute (Command: ke)
 Enables/disables the mute function.
Transmission
[k][e][][Set ID][][Data][Cr]
Data 00 : Turns on the mute function
(volume off).
01 : Turns off the mute function (vol-
ume on).
Ack
[e][] [Set ID][][OK][Data][x]
Data 00 : Turns on the mute function
(volume off).
01 : Turns off the mute function (vol-
ume on).
19. Volume (Command: kf)
 Adjusts the volume.
Transmission
[k][f][][Set ID][][Data][Cr]
Data Min: 0H - Max: 64H
(* Transmitted in hexadecimal code)
* See the data structure.
Ack
[f][] [Set ID][][OK][Data][x]
Data Min : 0H(Vol 0) - Max : 64H(Vol 100)
17. Picture Mode (Command: ns)
 Sets the picture mode.
Transmission
[n][s][][Set ID][][Data][Cr]
Data 00: Vivid
01: Standard
02: ECO
03: Cinema
04: Game
05: Expert 1
06: Expert 2
07: Black Mode
(* Transmitted in hexadecimal code)
Ack
[s][] [Set ID][][OK][Data][x]
Data 00: Vivid
01: Standard
02: ECO
03: Cinema
04: Game
05: Expert 1
06: Expert 2
07: Black Mode
(* Transmitted in hexadecimal code)
