Network
(Command: s n, 80 or 81 or 82)
Transmission
[s][n][ ][Set ID][ ][Data1][ ][Data2][ ]
[Data3][ ][Data4][ ][Data5][Cr]
Data 1 80: Set/check the temporary IP mode (auto/manual),
subnet mask, and gateway
81: Set/check a temporary DNS address.
82: Save the temporary set value, and check the
current network information
* When Data 1 equals 80,
Data 2 00: Auto
01: Manual
FF: Check the temporary IP mode (auto/manual),
subnet mask, and gateway
* When Data 2 equals 01 (Manual),
Data 3 Manual IP address
Data 4 Subnet mask address
Data 5 Gateway address
* When Data 1 equals 81,
Data 2 DNS address
FF: Check a temporary DNS address
* When Data 1 equals 82,
Data 2 80: Apply the temporarily saved IP mode (auto/
manual), subnet mask, and gateway
81: Apply the temporary DNS
FF: Current network information (IP, subnet gateway,
DNS)
* Setting examples:
1. Auto setting: sn 01 80 00
2. Manual setting: sn 01 80 01 010177223241 255255254000
010177222001 (IP:10.177.223.241, subnet:
255.255.254.0, gateway: 10.177.222.1)
3. Network Reader: sn 01 80 ff
4. DNS setting: sn 01 81 156147035018 (DNS: 156.147.35.18)
5. Applying the set value: sn 01 82 80 (apply the saved IP mode
(auto/manual), subnet mask, and
gateway), sn 01 82 81 (apply the saved
DSN)
* Each IP address is a 12-digit decimal number.
Acknowledgement
[n][ ][Set ID][ ][OK/NG][Data1][Data][x]
* The feature is supported only for a wired LAN.
* It may not be supported according to the model.
