LG DR1F9H User Manual
4
of 1
of 1 rating
146 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
3-6
No 33VT
Is VCC (33V) supplied to Q161
Emitor ?
YES
Check D126 on SMPS Board and Replace
NO
Is there 0V at Q152 Collector ?
YES
Check Q161 and Replace
NO
Check the
‘
TIMER H
’
signal
from µ-COM
NO
Is there 5V
at R180 and 0.7V at
Q152 Base?
YES
Check Q152 and Replace
YES
No 5.0VD
Is 5.3V at IC153 pin 1 ?
YES
Check 5.3V
A
on SMPS Board
NO
Is there 4V ~ 5V at IC153
pin 4 ?
YES
Check the
‘
PWR CTL
H
’
signal from
µ-COM
NO
Check IC153
and Replace
YES
20
22
Table of Contents
Section 1 Summary
3
Table of Contents
3
Product Safety Servicing Guidelines for Video Products
4
Servicing Precautions
5
General Servicing Precautions
5
Insulation Checking Prodedure
5
Electrostatically Sensitive Devices
5
Service Information for Eeprom IC Setting
6
Flash Upgrade
7
Loader Upgrade
9
Specifications
11
Section 2 Cabinet & Main Chassis
12
Cabinet and Main Frame Section
13
Exploded Views
13
Deck Mechanism Section(RS-01A)
14
Packing Accessory Section
15
Section 3 Electrical
16
Electrical Troubleshooting Guide
17
Power Supply on Smps Board
17
Vdr Part
17
Power Supply on I/O Board
19
Disc Not Recognized
26
System Circuit Part
26
When Playing Disc, no Audio Output
27
Optical / Digital Output
28
Tuner Audio Output
29
External Audio Input
30
Rgb / Component Video Signal When Play Disc
31
Composite / S-Video Signal When Play Disc
32
Tv, External Input Video Signal
33
DV(Ieee 1394) Input (Video/Audio) Signal
34
Block Diagrams
36
Power Block Diagram
36
Main Power Block Diagram
37
Video in Block Diagram
38
Video out Block Diagram
39
Audio in Block Diagram
40
Audio out Block Diagram
41
System Main Block Diagram
42
I/O Μ-COM BLOCK DIAGRAM
43
Scart Block Diagram(Scart Model Only)
44
Hdmi Block Diagram (Hdmi Model Only)
45
Memory Block Diagram (Memory Slot Model Only)
46
Circuit Diagrams
47
Main Power Circuit Diagram
48
Mpeg Circuit Diagram
49
A.latch/Flash/Ddr Circuit Diagram
50
Loader/DV Circuit Diagram
51
I/O Μ-COM CIRCUIT DIAGRAM
52
Tuner/Mpx/Adc/Dac/Jack Circuit Diagram
53
Decoder Circuit Diagram
54
Hdmi Circuit Diagram
55
Timer Circuit Diagram
56
Key Circuit Diagram
57
Waveforms
58
Circuit Voltage Chart
59
Main P.C.board(Top Side)
62
Printed Circuit Diagrams
62
Main P.C.board(Bottom Side)
63
Hdmi P.C.board(Optional Parts)
64
I/O P.C.board
64
Key P.C.board
65
Timer P.C.board
65
Power P.C.board
66
Section 4 Rs-01A Loader Part
68
Electrical Troubleshooting Guide
69
Recording Layer
83
The Difference of DVD-R/Rw, DVD+R/Rw Discs and DVD-Rom
83
Disc Materials
84
Disc Specification
84
Organization of the Inner Drive Area, Outer Drive Area, Lead-In Zone and Lead-Out Zone
88
Alpc Measurement System
91
Alpc Program
91
How to Use Test Tool
91
Execute Alpc Program
92
Optical Power Setting
94
Confirm Optical Power Setting Parameter
95
Optical Power Setting Parameter Range
96
Attachment. Optical Power Measurement
97
Block Diagram of the Pick-Up(Lpc-812R)
98
Internal Structure of the Pick-Up
98
Pick up Pin Assignment
99
Signal Detection of the P/U
100
Alpc (Automatic Laser Power Control) Circuit
101
Description of Circuit
101
Focus/Tracking/Sled Servo Circuit
102
Spindle Servo Circuit
104
Lic121 (An22113A) : Fep(Rf) Analog Signal Processor
105
Major IC Internal Block Diagram
105
Ic301 (Bd7956Fs) : CD-Rom/DVD-Rom 7Ch Power Driver
108
Circuit Diagrams
110
Dsp Circuit Diagram
110
Rf Circuit Diagram
111
Drive Circuit Diagram
112
Circuit Voltage Chart
113
Main P.C.board(Top View)
114
Printed Circuit Diagrams
114
Main P.C.board(Bottom View)
115
Other manuals for LG DR1F9H
