No. Pin Name Signal Description
45 T-
Tracking Actuator drive signal-
44 T+
Tracking Actuator drive signal+
43 Tilt-
Tilting Actuator drive signal-
42 Tilt+
Tilting Actuator drive signal+
41 F-
Focusing Actuator drive signal-
40 F+
Focusing Actuator drive signal+
39 GND(LDD)
Ground connection for LDD
38 VCC(LDD)
Power supply for LDD
37 ENABLE
Disables output current regardless of OUTEN(ENABLE Low:No lout)
36 OUTSEL
High:selects DVD LD, Low:CD LD
35 RSET
Input voltage for current amplifier
34 W1SET
Input voltage for current amplifier
33 W2SET
Input voltage for current amplifier
32 W3SET
Input voltage for current amplifier
31 VCC(LDD)
Power supply for LDD
30 GND(LDD)
Ground connection for LDD
29 GND(LDD)
Ground connection for LDD
28 OSCEN
TTL control for Oscillator Enable (High Enable)
27 W3DIS
LVDS control for output current (High Enable)
26 W3DISN
LVDS control for output current (Low Enable)
25 W2DIS
LVDS control for output current (High Enable)
24 W2DISN
LVDS control for output current (Low Enable)
23 W1DIS
LVDS control for output current (High Enable)
22 W1DISN
LVDS control for output current (Low Enable)
21 GND(FPD)
Ground connection for PDIC, FPD, TEMP
20 TEMP
Output voltage for controlling temperature
19 FPD-OUT
APC amplifier output
18 VREF(FPD)
APC amplifier reference voltage output
17 GND(TEMP)
Ground connection for PDIC, FPD, TEMP
16 VCC(FPD)
Power supply for FPD
15 SW2(FPD)
FPD output gain Select (High : CD, Low:DVD)
14 RF-
Signal PDIC RF negative differential output
13 RF+
Signal PDIC RF positive differential output
12 SW1(PDIC)
PDIC output gain Select (L/M/H)
11 D
Signal PDIC output D
10 C
Signal PDIC output C
9EF3
Signal PDIC output EF3
8EF2
Signal PDIC output EF2
7B
Signal PDIC output B
6A
Signal PDIC output A
5EF1
Signal PDIC output EF1
4EF4
Signal PDIC output EF4
3 GND(PDIC)
Ground connection for PDIC, FPD, TEMP, LDD
2 VCC(PDIC) Power supply for PDIC(+5V)
1 VC(PDIC)
Reference voltage input for PDIC)
