8. Installation
17
MULTI Standard
Indoor Unit
* According to product type, model line up, sales region..etc, applicability of each chassis could be different.
CAUTION
In case that the unit is installed near the sea, the installation parts may be corroded by salt. The
installation parts (and the unit) should be taken appropriate anti-corrosion measures.
SV chassis
Left rear piping
Right rear piping
43
43
140
150
167 Unit Outline
167
Installation plate
(Unit : mm)
