MULTI Standard
9. Piping diagrams
21
Outdoor Unit
A3UQ24GFAB
Description PCB Connector
Condensing temperature Thermistor CN_MID
Inlet air temperature Thermistor CN_AIR
Discharge temperature Thermistor CN_DISCHARGE
