15
GENERAL INFORMATION
ENGLISH
Model name and related information
*1 : tested under EN14511
(water temperature 30 °C ’ 35 °C at outdoor ambient temperature 7 °C / 6 °C)
• All appliances were tested at atmospheric pressure.
Type Air-to water Heat Pump (For High Temperature)
Model Unit Indoor Outdoor
Power Supply Ø, V, Hz 1, 220-240, 50
Capacity Heating
kW
*1
16
kcal/h 13,760
Btu/h 54,600
Net Weight kg(lbs) 84(185) 89(196)
Refrigerant
Type R134a R410A
Amount kg(lbs) 1.8(3.9) 3.8(8.3)
Sound Power Level(PWL) dB(A) 63 63
Maximum Running Current A 20.2 18.9
To Next Page
