INSTALLATION
ENGLISH
Installation Space
Indoor Unit
- The following values are the least space for installation. If any service area is needed for service
according to field circumstance, obtain enough service space.
- The unit of values is mm.
Outdoor Unit
- The following values are the least space for installation.
If any service area is needed for service according to field circumstance, obtain enough service
space.
- The unit of values is mm.
(Unit: mm)
400520300
Service space
(front side)
330
600
Piping space
(front side)
Service space
(left side)
100100100100
200
10801080
H-Beam supporter
space
(Unit: mm)
