23
GENERAL INFORMATION
ENGLISH
Typical Installation Example
Some installation scenes are presented for example. As these scenes are conceptual figures,
installer should optimize the installation scene according to the installation conditions.
Floor Heating only
Floor Heating + Hot water
Hot water only
Floor heating loopFan coil unit
Radiator
Floor heating loopFan coil unit
Sanitary
water
tank
Hot water
Cold water supply
Radiator
Sanitary
water
tank
Hot water
Cold water supply
Pump
3way valve
Bypass valve
