CONFIGURATION
As is designed to satisfy various installation environment, it is important to set up
system correctly. If not configured correctly, improper operation or degrade of performance can
be expected.
DIP Switch Setting
General Information
Indoor PCB
OFF
ON
SW1
1 2 3 4
OFF
ON
1 2 3 4
OFF is selected ON is selected
OFF
ON
SW2
1 2 3 4 5 6 7 8
SW3
1234
1234
1234567 8
Turn off electric power supply before setting DIP switch
• Whenever adjusting DIP switch, turn off electric power supply to avoid electric shock.
CAUTION
!
