48
PIPING AND WIRING FOR OUTDOOR UNIT
ENGLISH
How to connect wirings
Communication cable
Power cable
Earth
3(A) 4(B)
Terminal block
of indoor unit
Terminal block
of indoor unit
Terminal block of outdoor unit
ODU. B ODU. A IDU. B IDU. A CEN. B CEN. A DRY1 DRY2 GND 12V
Communication cable
Power cable
