7200 Series UPS User Manual Chapter 7 - 1+1 Parallel System
Single Module and 1+1 Parallel System Installation procedure (Common battery)
document in response to "powersure ups"
Page 7-11
Issue 6
(03/98)
Cable A: 5 wires + screen
Aux. Batt. Distribution box Battery Cabinet or Batt. Switch Box
Connector X3 ( F ) Connector X1 on 4520067T PCB ( screws )
Pin 1 not connected Screen
Pin 2 Pin 5
Pin 3 Pin 4
Pin 4 Pin 3
Pin 5 Pin 2
Pin 6 Pin 1
Cable B: 2 wires + screen
Connector X1 ( F ) 2nd Temperature Sensor in Battery ( screws )
Pin 12 Screen Pin 3 not connected
Pin 11 Pin 2
Pin 10 Pin 1
Cables C: 5 wires + screen
Connector X3 on UPS cabinet Connector X2 or X3 on Aux. Batt. Distrib. Box
Pin 1 not connected Pin 1 screen
Pin 2 Pin 2
Pin 3 Pin 3
Pin 4 Pin 4
Pin 5 Pin 5
Pin 6 Pin 6
Cables D: 3 wires + screen
Cables of removed T11 in UPS cabinets Connector X2 or X3 on Aux Batt. Distrib. Box
Wire 68 Pin 10
Wire 69 Pin 9
Wire 70 Pin 8
Not connected Pin 7 screen
How to build cables of fig. 7-6
