Operation and Display Panel
Liebert
®
GXT4
™
20
Figure 19 Status screens
CONFIGURATION Screen
Select MAIN MENU > CONFIGURATION to enter the Configuration menu. This menu has seven
submenus, as shown in Figure 20.
Figure 20 CONFIGURATION screen
In the CONFIGURATION screen, press the Up or Down button to move the cursor to the required
item, then press the Enter button to enter a submenu or set its parameters.
VOLTAGE : 120V
FREQUENCY : 60HZ
CURRENT : 17.6A
POWER : 2112 KWH
OUTPUT
CAP : 90%
WATT : 1620W
VA : 1800VA
LOAD
VOLT : 120V
FREQ : 60 HZ
CURR : 18.6A
POWER : 97KWH
INPUT
CAPACITY : 90%
RUNTIME : 100MINS
VOLTAGE : 80V
BATTERY
05D 15H 30M
TIME SINCE STARTUP
1. UPS
2. BATTERY
3. ECO MODE
4. OUTLET 1
5. OUTLET2
6. LCD
7. FACTORY DEFAULT
To Next Page
