Liebert GXT4 User Manual

Operation and Display Panel
27 Liebert
®
GXT4
™
Log Screen
Select MAIN MENU -> 4 LOG to enter the LOG screen. This screen has two submenus, as shown in
Figure 36.
Figure 36 Log screens
CLEAR LOG Screen
Select MAIN MENU > LOG > CLEAR LOG to enter the CLEAR LOG screen, as shown in Figure 37.
Figure 37 Clear Log screen
Press the Up or Down button to move the cursor to the required item. Press the Enter button to
confirm the settings.
ABOUT Screen
Select MAIN MENU> ABOUT to enter the ABOUT screen, as shown in Figure 38.
Figure 38 About screen
The ABOUT screen displays UPS model, serial number, software version and hardware version.
1VIEW LOG
2 CLEAR LOG
255 OD 1H 17m AGO
UPS switch to Online
mode
254 /255
DO YOU WANT TO
CLEAR EVENT LOGS?
YES NO
PN: GXT4-2000 RT230
SN:1XXX60XXX1AFCXX
FW VER: U100D100
HW VER: H100

Liebert GXT4 Specifications

General

Form Factor	Tower/Rack Mount
Power Factor	0.9
Battery Type	Sealed Lead-Acid (SLA)
Backup Time	Varies by model and load
Waveform Type	Sinewave
Communication Ports	USB, RS-232
Topology	On-line Double Conversion
Output Frequency	50/60 Hz +/- 0.1 Hz
Typical Recharge Time	3 hours to 90%
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-15°C to 45°C (5°F to 113°F)
Humidity	0-95% non-condensing
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Output Voltage	208/220/230/240VAC
