Operation and Display Panel
Liebert
®
GXT4
™
22
ECO Mode Screens
Select MAIN MENU > CONFIGURATION > ECO MODE to enter the ECO MODE screens, as shown
in Figure 23.
Figure 23 ECO Mode screen
Press the Up or Down button to move the cursor to the required item, and press the Enter button to
confirm the settings.
Outlet1 Screen
Select MAIN MENU > 2 CONFIGURATION > 4 OUTLET1 to enter the OUTLET1 screen. This menu
has two submenus, as shown in Figure 24.
Figure 24 Outlet1 screen
ON
ECO MODE
3 Hz
FREQUENCY TOLERANCE
10%
VOLTAGE TOLERANCE
5 MINS
REQUALIFICATION TIME
OUTLET1
1 OUTLET CONTROL
2 OUTLET SETTING
