Liebert NX series User Manual

Operator Control and Display Panel
14
2.12.3 UPS Help Screen
Press the HELP key below the LCD to display the Help window shown in Figure 12. (Press the
HELP key again to exit the Help window.)
Figure 12 Help screen
2.12.4 Screen Saver Window
If there has been no interaction with the NX’s LCD for 2 minutes, the screen saver window appears. It
remains on the LCD for 2 minutes, then the screen will go dark. The LCD will become active again
when any key is pressed.
Figure 13 Screen saver window
F2 F4 HELPF1 F3
Help information
Select the previous menu item
Select the current record window
Q3
Q2
Q1
Q5
Press help key back to main menu
F2 F4F1 F3
2004-01-22 12:30:36
Single Normal
Liebert NXb
Press any key back to main menu
30kVA-3X3
HELP

Liebert NX series Specifications

General

Frequency	50/60 Hz
Display	LCD
Topology	Double Conversion
Input Voltage	208/220 VAC
Output Voltage	208/220 VAC
Communication	SNMP
Operating Temperature	0 to 40°C
Battery Type	VRLA
Humidity	0 to 95% (non-condensing)
Dimensions	Varies by model. See product documentation.
Weight	Varies by model. See product documentation.
Storage Temperature	-15-50°C (5-122°F)
