UPS Status Messages
35
71 Unit Off Confirm Unit Turned Off Confirm
72 System Off Confirm Parallel System Turned Off Confirm
73 Fault Reset Fault Rest
74 Alarm Silence Alarm Silence
75 Turn On Fail Turn On Fail
76 Alarm Reset Audible Alarm Reset
77 Bypass Mode UPS in Bypass Mode
78 Normal Mode UPS in Normal Mode
79 Battery Mode UPS in Battery Mode
80 Joint Mode UPS in Inverter Mode
81 UPS Shutdown UPS Shutdown, output power-down
82 Output Disabled UPS Output Disabled
83 Generator Connected Generator is connected and a signal is sent to ups
84 Input Disconnect Open Input Disconnect Open
85 Input Disconnect Closed Input Disconnect Closed
86 Maint. Disconnect Open Maintenance Disconnect Open
87 Maint. Disconnect Closed Maintenance Disconnect Closed
88 Reserved
89 Rotary Sw. Test Pos. Rotary switch is in test position.
90 Rotary Sw. Normal Pos. Rotary switch is in normal position.
91 Rotary Sw. Bypass Pos. Rotary switch is in bypass position.
92 Rotary Sw. Maint. Pos. Rotary switch is in maintenance position.
93 Bypass Disconnect Open Bypass Disconnect Open
94
Bypass Disconnect
Closed
Bypass Disconnect Closed
95 Output Disconnect Open Output Disconnect Open
96 Output Disconnect Closed Output Disconnect Closed
97 Battery Contactor Open Battery Contactor Open
98 Battery Contactor Close Battery Contactor Close
99 Battery Reverse Connect the battery again and check the wiring of batteries
100 No Battery Check the battery and the wiring of batteries
101 Auto start After UPS was shutdown at EOD, inverter auto starts when utility restore.
102 BCB closed BCB closed from dry contact signal.
103 BCB open BCB open from dry contact signal.
104 Battery Float Charging Battery is float charging
105 Battery Boost Charging Battery is boost charging
106 Battery Discharging Battery is discharging
107 Battery Period Testing Battery is period self-testing.
108 Batt. Capacity Testing Battery is capacity self-testing.
109 Batt. Maint. Testing Battery is maintenance self-testing.
110 UPS System Testing UPS System is testing
111 Inverter in Setting Inverter is in parameter setting
112 Rectifier in Setting Rectifier is in parameter setting
Table 8 UPS status messages (continued)
No. Event Message Description / Suggested Action (if any)
