Lighthouse S3100/S5100/Boulder Counter Operating Manual
6-34 248083389-1 Rev
• The third screen displays the arrow in the upper left corner. The
arrow will have to be touched three times to ensure calibration as
Figure 6-44 illustrates this.
Figure 6-44 Alignment Screen 3
• The fourth alignment screen shown in Figure 6-45, displays the
arrow in the at the bottom center of the screen. Touch the arrow
three times to finish the alignment process.
Figure 6-45 Final Alignment Screen
