Lightware DVI-OPT-TX220-Pro


10. Appendix DVI-OPT-220-Pro series – User's Manual 37

Mem. Resolution
F1 640 x 480 @ 60.0 Hz
F2 640 x 480 @ 75.0 Hz
F3 848 x 480 @ 60.0 Hz
F4 800 x 600 @ 50.0 Hz
F5 800 x 600 @ 60.30 Hz
F6 800 x 600 @ 74.99 Hz
F7 1024 x 768 @ 49.98 Hz
F8 1024 x 768 @ 60.0 Hz
F9 1024 x 768 @ 75.2 Hz
F10 1152 x 864 @ 75.0 Hz
F11 1280 x 768 @ 50.0 Hz
F12 1280 x 768 @ 59.92 Hz
F13 1280 x 768 @ 75.0 Hz
F14 1360 x 768 @ 60.1 Hz
F15 1364 x 768 @ 50.0 Hz
F16 1364 x 768 @ 59.93 Hz
F17 1364 x 768 @ 74.98 Hz
F18 1280 x 1024 @ 50.0 Hz
F19 1280 x 1024 @ 60.1 Hz
F20 1280 x 1024 @ 75.1 Hz
F21 1366 x 1024 @ 59.99 Hz
F22 1400 x 1050 @ 49.99 Hz
F23 1400 x 1050 @ 59.99 Hz
F24 1400 x 1050 @ 75.0 Hz
F25 1680 x 1050 @ 59.99 Hz
F26 1600 x 1200 @ 50.0 Hz
F27 1600 x 1200 @ 60.0 Hz
F28 1920 x 1200 @ 59.55 Hz
F29 1920 x 1200 @ 50.0 Hz
F30 1440 x 480i @ 60.3 Hz
Mem. Resolution
F31 640 x 480 @ 59.94 Hz
F32 720 x 480 @ 59.92 Hz
F33 1440 x 576i @ 50.6 Hz
F34 720 x 576p @ 50.0 Hz
F35 1280 x 720p @ 50.0 Hz
F36 1280 x 720p @ 60.0 Hz
F37 1920 x 1080i @ 50.3 Hz
F38 1920 x 1080i @ 50.0 Hz
F39 1920 x 1080i @ 60.5 Hz
F40 1920 x 1080 @ 24.0 Hz
F41 1920 x 1080 @ 24.99 Hz
F42 1920 x 1080 @ 30.0 Hz
F43 1920 x 1080 @ 50.0 Hz
F44 1920 x 1080 @ 49.99 Hz
F45 1920 x 1080 @ 60.0 Hz
F46 2048 x 1080 @ 49.99 Hz
F47 2048 x 1080 @ 50.0 Hz
F48 2048 x 1080 @ 59.99 Hz
F49 1920 x 1200 @ 59.55 Hz
INFO: Factory EDIDs do not include HDMI support.
Maximum Extension Distances
The below table shows the transmission distances via optical cable
between the DVI-OPT-220-Pro series extenders depending on the
cable quality and pixel clock frequency
Resolution,
pixel clock rate
OM1
(62.5/125)
OM2
(50/125)
OM3
(50/125)
OM4
(50/125)
1080p@60Hz 24 bpp Not supported 600 m 1200 m 2500 m

Parameter 
RS-232 settings 9600 Baud, 8 data bit, 1 stop bit, no parity
Emulated EDID F49 (1920x120059.55Hz Universal EDID)
Laser enabled Yes




