Lightware UCX-4x2-HC30 - Mechanical Drawings

12. Appendix UCX series – User's Manual 160

Mechanical Drawings
INFO:  UCX-2x1-HC30, UCX-2x2-H30, UCX-4x2-HC30 models have the same size. Dimensions are in mm.
UCX-2x1-HC30, UCX-2x2-H30, UCX-4x2-HC30 models
26
246
150
140.3
8753,3
178.5
21.25
Mounting hole
Mounting hole
POWER LED
67
16735
Power supply




