 UCX series – User's Manual 99



Request and Response #ocs
ɯ  <ip>
ɮ header: 200·OK
ɮ body: <value>
Parameters
Parameter Parameter description  
<value> The input value of the OCS pin.
High
high level
Low
low level
Example
ɯ  
ɮ header: 200 OK
ɮ  
Set the Sensor Type
Request and Response
ɯ  <ip>
ɯ body: <sensor_type>
ɮ header: 200 OK
ɮ body: <sensor_type>
Parameters
Parameter Parameter description  
<sensor_type> 
input level means the occupancy.
Active low
Occupancy status is
'Occupied' when the
input level is low.
Active high
Occupancy status is
'Occupied' when the
input level is high
(default value).
Example
ɯ  
ɯ body: Active low
ɮ header: 200 OK
ɮ body: Active low

Request and Response
ɯ  <ip>
ɮ header: 200·OK
ɮ body: <status>
Parameters
Parameter Parameter description  
<status> It reports the occupancy
state of the room depending
on the sensor type.
Free


when SensorType=Active low and Inputlevel=High
Occupied

Inputlevel=High or

Example
ɯ  
ɮ header: 200 OK
ɮ body: Free




