11. Appendix UMX-TPS-TX100 series – User's Manual 172

Mechanical Drawings
UMX-TPS-TX100 series
UMX-TPS-TX140 can be seen in the pictures, but the dimensions are the same for all standalone transmitter
models.
Front View
Rear View
Bottom View
VIDEO AUDIO
DVI-A Video
Autoselect
HDCP
Audio2
DVI-D
DP
DVI-D
DP
SHOW
ME
AUDIO
SELECTINPUT STATUS
VIDEO
SELECT
HDMI HDMI
VGA
Audio1
RESET
AUDIO1 IN HDMI IN
2
DP IN
3
VGA IN
221
26
Ethernet IR OUTIR IN
RS-232
LIVE
12V 1A DC
PIN: 2.1mm
TX RX 2
3
4
5 6
7
SRVC
LINK
RS-232 GPIO
L R
1
TPS OUT PoE
( )
AUDIO2 IN
5
DVI-I IN
4
5
178.5
20
84
M3 thread
M3 thread
Top View
Side View
UMX-TPS-TX140
Universal TPS Transmitter
INPUT STATUS LED FUNCTIONS
Blinking: Selected input has no signal
Continuous ON: Signal present on active input
AUDIO SELECT:
VIDEO SELECT:
Made in EU, Hungary
RoHS
Sn:
Rear LED functions Port legend
LIVE Video only
Audio only
Video with embedded audio
RS-232
SRVC
Fast blinking (0.5 sec): Firmware upgrade mode
Continuous ON: Powered but no operation
OFF: No power
OFF: Pass-through mode
Blinking (1 sec): Normal operation
Blinking: Command injection mode
ON: Control mode
Reserved
OFF: No TPS link
TPS link
Blinking: Low power mode
ON: TPS link good
DVI-DHDMI DPVGA
Autoselect
DVI-A
HDMI emb. DP emb.Audio1
Audio2
DVI-D emb.
For best performance use AWG23
CAT6 or CAT7 SFTP cable
Device can be remote powered over TPS link with PoE
(IEEE 802.3af)
2
100.4




