ETL marking
Due to space limitations, the complete ETL marking demands are not represented on the marking plates.
The full ETL recognised component markings are shown here:
C/N 120690
Conforms to ANSI/AAMI Std. ES60601-1
Cert. to CSA Std. C22.2 No. 60601-1
C/N 9901916
Conforms to ANSI/AAMI Std. ES60601-1
Cert. to CSA Std. C22.2 No. 60601-1
C/N 4008003
Conforms to ANSI/AAMI Std. ES60601-1
Cert. to CSA Std. C22.2 No. 60601-1
C/N 4008004
Conforms to ANSI/AAMI Std. ES60601-1
Cert. to CSA Std. C22.2 No. 60601-1
C/N 4008005
Conforms to ANSI/AAMI Std. ES60601-1
Cert. to CSA Std. C22.2 No. 60601-1
C/N 4008623
Conforms to ANSI/AAMI Std. ES60601-1
Cert. to CSA Std. C22.2 No. 60601-1
C/N 4008838
Conforms to ANSI/AAMI Std. ES60601-1
Cert. to CSA Std. C22.2 No. 60601-1
C/N 4008671
Conforms to ANSI/AAMI Std. ES60601-1
Cert. to CSA Std. C22.2 No. 60601-1
C/N 4009507
Conforms to ANSI/AAMI Std. ES60601-1
Cert. to CSA Std. C22.2 No. 60601-1
Mounting
Actuator:
Do not use any other screws for the mounting brackets than those recommended by LINAK
®
. If longer screws are used, they will come into contact
with the inner parts of the actuator. This will result in an irregular operation or even damage the actuator.
During mounting, the actuator must always be:
• Fixed to protect it against torque and bending. See Figure 2 on the next page.
• Fixed so that it is restrained, but free to move on its mountings. See Figure 3 on the next page.
• Fixed in brackets, which can take up the torque reaction. See Figure 3 on the next page.
• Mounted at right angles so that the right angle requirement is observed. See Figure 4 on the next page.
• Mounted with correct bolt dimension.
• Mounted with bolts and nuts made of high quality steel grade (for example 10.8). No thread on bolts inside the back fixture or the piston rod eye.
• Bolts and nuts must be protected from being able to fall out.
• Inspect the actuator for damage before mounting. A damaged actuator must not be mounted. Check for instance for damaged packaging.
• Do not use a too high tourque when mounting the bolts for the back fixture or the piston rod eye
Control boxes:
• The mounting screws on the control box must be tightened with a maximum torque of 1 Nm
• The mounting surface to which the control box is attached should have a surface evenness better than ± 0.5 mm.
• Systems must not be installed/deinstalled while in operation.
• Control boxes with a wet alarm must be mounted as shown on figure 5 on the next page.
• Nuts and bolts must be made of steel.
• Nuts and bolts must be tightened securely.
• For control boxes with earth connection (Class 1), the nut must be tightened with a torque of 1 - 1.2 Nm.
Cables:
It is important to remove the transport plastic bag before using the cable.
Accessories:
The mounting screws on accessories must be tightened with a maximum torque of 1 Nm
• The mounting surface to which the accessory is attached should have a surface evenness of more than ± 0.5 mm
• Systems must not be installed/deinstalled while in operation
• Nuts and bolts must be made of steel
• Nuts and bolts must be tightened securely
Controls:
The mounting screws on the controls must be tightened with a maximum torque of 1 Nm
• The mounting surface to which the accessory is attached should have a surface evenness of more than ± 0.5 mm
• Systems must not be installed/deinstalled while in operation
• Nuts and bolts must be made of steel
• Nuts and bolts must be tightened securely
For further instructions regarding mounting, see the data sheet for the individual product or in chapter 5, 6 or 8
in this manual.
