The Under Bed Light (UBL2) provides a powerful light with
a good distribution. The UBL2 is to be used for beds within
hospitals, nursing homes and in homecare.
The Under Bed Light makes it easier for patients and other
people in need of care to find their way at night in the dark
to prevent falling accidents and to make them feel safe.
15. Under Bed Light 2 (MEDLINE
®
CARELINE
®
)
Usage:
• Operating temperature: + 5 °C to + 40 °C
• Storage temperature: - 10 °C to + 50 °C
• Relative humidity: 10 % to 80 % at + 30 °C not condensing
• Atmospheric pressure: 700 to 1060 hPa
• Approvals: EN62471, IEC60601-1
Recommendations and Precautions
• If 2 or more UBL2 products with dimming function are connected to the same application, it is recommended to have a factory reset key to be
able to synchronize the dimming direction and light intensity if one of the UBL2s is replaced.
• Screw holes in application are needed for mounting. Inform the customer to use M4 Ø12 screws with Ø12 washer, when mounting the UBL2.
Max. torque 2.5 Nm.
• Hot-plugging:
Removing or adding any OpenBus™ cables is not allowed when the CB is powered by mains supply!
If needed anyway, follow the below procedure:
1. Remove mains and wait 5 sec.
2. Mount or dismount the required cables
If this procedure is NOT followed, it may result in a damaged OpenBus™ driver circuit. The risk of a damaged circuit increases if the accessory
has a high start current (in rush current).
• There can be a risk of conflict with other OpenBus™ accessories, like HB, ACP, etc. when using the OpenBus™ UBL2, it is therefore
recommended to make a system/bit overview.
• Always use locking mechanism and O-ring
• Sockets not used must be fitted with blind plugs to ensure IP degree
• The UBL2 must be mounted on a plane surface and casing must not be subject to impact or any kind of stress.
16. WET Sheet (MEDLINE
®
CARELINE
®
)
The WET Sheet is an OpenBus™ product and is a part of the WET Detection solution.
The WET Detection solution consists of the WET Sheet, the MJB8 and a WET Sheet cable.
Recommendations
• The WET Sheet is a wearing part which is not covered by the standard LINAK warranty
The WET Sheet warranty is valid until the product has been put into use
• The WET Sheet is not a stand-alone article and must be included as part of an application e.g. the MJB8
• The WET Detection will not detect liquid without conductivity e.g. demineralised water
• The WET Sheet is not intended for outdoor use
• The WET Sheet is not a life-supporting unit
• Mechanical pressure on the WET Sheet can destroy the thread and connectors
• It is recommended to change the WET Sheet cable after 500 connections
• The sheet and connector must be placed properly to minimise the risk of bedsore
• The WET Sheet connector is not to be exposed to direct moisture etc. urine or sweat.
Place the connector away from the user, for instance on the side of the bed and downwards
• To ensure the right WET Detection functionality do not use layers on top of the WET Sheet, e.g. a turning sheet
• The recommended temperature for washing is 60 °C. Washing at 85 °C is acceptable, however,
this will reduce the lifetime
• Tumble drying at medium heat, however, line drying is recommended
• The typical number of washing cycles is up to 50, but will depend on the washing conditions
• The WET Sheet should be washed before use and must be completely dry before it is connected
