Page 36 of 192
Connection diagrams:
Standard electrical end stop and potential free end stop - no positioning
23XXXXXX01XXXXX
Dual Hall digital positioning
23XXXXXX02XXXXX
Dual Hall PNP positioning
23XXXXXX03XXXXX
6 poles connector
6 poles connector
6 poles connector
Standard electrical end stop - no positioning
23XXXXXX00XXXXX
Note: If reversed driving is wanted this has to be done by using different cables.
Note: Connection colours only fit with “open-end cables.
BLUE
BROWN
M
_
M+
M
M
_
M+
M
IN
Common
OUT
BLUE
GREEN
BROWN
YELLOW
RED
BLUE
GREEN
BROWN
YELLOW
RED
M
_
M+
M
HALL A
VCC +
HALL B
GND
_
BLACK
