5 Servicing
Troubleshooting
Fuse assignment special equipment
e3861300
1
2
3
4
5
6
7
89
10
11
12 13 14
15 16 17
18 19 20
2122
23242526272829
30
31
32
33
34
35
36
1 Working headlight
item 1, 2 (5F40) *, 15A
2 Working headlight
item 3, 4 (5F41) *, 15A
3 Working headlight
item cross tra-
verse or 5, 6 (5F42
), with 1 working
headlight 7.5A,
with 2 working head-
lights 15A
4 Working headli
ght item 7, 8 (5F43), with
1 working head
light 7.5A, with 2 working
headlights 15
A
5 Windscreen wi
pers general (9F80), 2A
6 Wash pumps (9F
81), 10A
7 Front windscr
een wiper (9F82) 10A
8 Rear and roof w
indscreen wiper (9F83) 10A
9 Blower heatin
g (9F71) 20A
10 Coding heatin
g(9F72)1A
11 Seat heater (9
F73), 15A
12 Socket 12V (9F9
1), 15A
13 Relay coil 70A (
9F94) relay (positive lead
switching)
14 not assigned
15 not assigned
16 not assigned
17 Lights (5F20)
,15A
18 Hazard warning
lights (5F21), 10A, warning
flashing ligh
t when reversing with brake light
without illu
mination (5F27), 5A
19 Brake light illumi
nation (5F26) 5A, brake
light illuminati
on higher (5F26) 5A, brake
light illuminat
ion higher (Japanese ver-
sion) (5F26) 7.
5A, warning flashing light
when reversin
g with brake light without illu-
mination (5F
26) 5A,
20 Dipped beam l
eft (5F22) 7.5A
21 Dipped beam r
ight (5F23) 7.5A
22 Side lights le
ft (5F24) 5A
23 Side lights ri
ght (5F25) 5A
24 Interior ligh
t(5F28)2A
25 not assigned
26 not assigned
27 not assigned
28 not assigned
29 not assigned
30 not assigned
31 not assigned
32 not assigned
33 Rotating signa
l beacon/flashing light via
switch/switch
latch (4F50) 5A
34 Reversing sign
al (warning light/rotating
signal beacon
/flashing light (4F51) 10A
35 Radio positiv
e lead switching (9F92)
36 Radio positiv
e lead switching (9F93) 5A
136 Operating Instructions – 386 807 1001 EN – 03/2006
