Technical data 6
Type sheet E 16, (battery 48 V / 6PzS / 660L) Edition 09/2005
4 Tilt lift mast/fork carriage, forward/reverse
4.19
Total length
l1 [mm]
2961
4.20
Length including fork back l2 [mm]
2061
4.21 Total width
b1/b2 [mm] 1050 (1090)
4.22 Fork dimensions
s/e/l [mm]
40 x 80 x 900
4.23
Fork carriage DIN 15173, Class / Form A, B
2A
4.24
Fork carriage width
b3 [mm]
1040
4.31
Floor clearance with load under lift mast
m1 [mm]
97
4.32 Floor clearance middle wheel base
m2 [mm]
0
4.33
Working width for pallet 1000x1200 transverse
Branch
[mm]
3387
4.34
Working width for pallet 800x1200 longitudinal
Branch
[mm]
3511
4.35
Radiuses of curvature
Wa [mm]
1696
4.36
Smallest pivot point radius
b13 [mm]
0
5 Performance data
5.1
Travelling speed with / without load
km / h 16 / 16
5.2
Lifting speed with / without load
m/s 0.4 / 0.6
5.3
Lowering speed with / without load
m/s 0.58 / 0.47
5.5
Traction force with / without load
N
5.6
Max. traction force with / without load
N 7000 / 7285
5.7
Climbing capability with / without load
%
5.8
Max. climbing capability with / without load
%
5.9 Acceleration time with / without load
s
<5 / <4.5
5.10
Operating brake
hydraulic /
mechanical
6Drive/motor
6.1
Drive motor, performance (S2 60 min)
kW 4.6
6.2
Lift motor, performance at (S3 15%)
kW 10
6.3
Battery according to DIN 43531 / 35 / 36 A, B, C, no
43531 A
6.4
Battery type, battery voltage, rated capacity K5
/V/Ah
48 / 6PzS / 660L
6.5
Battery weight kg
1013
6.6
Energy consumption according to VDI cycle
kWh / h
