Technical data 6
Type sheet H 25, as at 05/2008
4 Basic dimensions
4.4
Lift
h3 [mm]
3050
4.5
Raised mast height
h4 [mm]
3840
4.7
Overhead guard height (cab) h6 [mm]
2210
4.8
Seat height (min/max) h7 [mm]
1105
4.12
Coupling height h10 [mm]
698
4.19
Overall length l1 [mm]
3727
4.20
Length including fork back l2 [mm]
2727
4.21
Overall width
b1/b2 [mm]
1256
8
4.22 Fork arm dimensions
s/e/l [mm]
45 x 100 x 1000
4.23
Fork carriage DIN 15173, class/form A, B
2A
4.24
Fork carriage width
b3 [mm]
1150
9
4.31
Ground clearance at mast
m1 [mm]
119
4.32 Ground clearance, centre of wheelbase
m2 [mm]
173
4.33
Aisle width for pallet 1000x1200 crosswise
Ast [mm]
4065
4.34
Aisle width for pallet 800x1200 longitudinal Ast [mm]
4265
4.35
Turning radius
Wa [mm]
2420
4.36
Smallest pivot point distance
b13 [mm]
580
5 Performance data
5.1
Driving speed with/without load
km/h 22/22
5.2
Lifting speed with/without load
m/s 0.47 / 0.48
5.3
Lowering speed with/without load
m/s 0.52 / 0.54
5.5
Pulling force with/without load
N
19,790 / 15,150
5.7
Climbing capability with/without load
%
10
32 / 33
5.9 Acceleration with/without load
s
5.6/4.8
5.10 Service brake
Hydrostatic
8
1337 mm for SE 28x12.5-15; 1611 mm for SE dual fitment 7.00-12; 1289 mm for air
27x10-12/20 PR; 1337 mm for air 250/75 R12; 1624 mm for air dual fitment 7.00-12.
9
For dual fitment 1600 mm.
10
On short slopes, driving over obstacles (see section: Driving)
