LINET MULTICARE 2015 User Manual

Project SERVICE MANUAL
Date
05-2017
Version 05
81/84
9 LINIS
9.1 Description of Linis items displayed on LCD (Multiboard)
Page 1
1
AD P Col 0
AD potentiometer column 0
1
AD Accel X
AD accelerometer PCB x
2
AD P Col 1
AD potentiometer column 1
2
AD Accel Y
AD accelerometer PCB y
3
AD P Col 2
AD potentiometer column 2
3
AD Accel BR
AD backrest accelerometer
4
AD I Col 0
AD current - column 0
4
AD Accel LR
AD thighrest accelerometer
5
AD I Col 1
AD current - column 1
5
AD Temp
AD temperature
6
AD I Col 2
AD current - column 2
6
AD Stop
AD stop
7
AD I Mot BR
AD backrest motor current
7
AD RE+
AD RE+
8
AD I Mot LR
AD legs motor current
8
AD UM
AD Batje
9
AD Accu U
AD battery Ud
9
AD 12V
AD 12V
10
AD Accu I
AD battery Id
10
AD 5V
AD 5V
11
Oper Code
Operation codes (see 9.3)
11
Charge Stat
Charging regime
12
Stop Code
Bed stop code (see 9.2)
12
System Err
System fault (see 7.4)
Page 2
1
C Calib B
Calibration byte
1
Scale C1
Tensometer constant 1
2
C Conf B1
Bed settings 1 – bin
2
Scale C2
Tensometer constant 2
3
C Conf B2
Bed settings 2 – bin
3
Scale C3
Tensometer constant 3
4
C Conf B3
Bed settings 3 – bin
4
Scale C4
Tensometer constant 4
5
C Conf
Bed settings hex –C3,C2,C1
5
Scale CG
Gravitational constant
6
Oload F
Number of overloads
6
Scale CCal
Calibration constant
7
Oload 260V
Number of overstrains>260V
7
Scale NoCal
Number of calibrations
8
Oload 280V
Number of overstrains>280V
8
Scale Graph
Scale value saving
9
Oload MaxV
Maximum value of overstrain
9
Scale T1
Tensometer value 1
10
Oload Temp
Number of temperature
overstrain
10
Scale T2
Tensometer value 2
11
Angle LR
Angle of calf rest
11
Scale T3
Tensometer value 3
12
Abs Weight
Absolute weight
12
Scale T4
Tensometer value 4
