D9U003VB3-0101_0448/65
11.2.8 FowlerBoost
Fowler Boost provides increased support for the patient when sitting up in bed in APT or CLP mode. SCU activates
Fowler Boost automatically when backrest is raised and Fowler Boost cable is connected to SCU.
ActivatingFowlerBoost
Raise backrest.
Whenbackrestisraised:
When the backrest is raised the SCU automatically increases the mattress pressure (single point pressure increase
at 30 degrees for Virtuoso Overlay and Virtuoso Mattress Replacement (Air + Alternating Air Base), linear pressure
increase within 11 - 46 degrees for Virtuoso With Head & Heel Zoner (Air + Alternating Air Base) and Virtuoso Pro).
The Fowler Boost Indicator 6
ssure is achieved.
Once the pressure is achieved, the pressure range indicator 3 will be permanently on.
DeactivatingFowlerBoost
Lower backrest.
Whenbackrestislowered:
When the Backrest is lowered the SCU automatically reduces the mattress pressure.
The Fowler Boost Indicator 6 will extinguish and the pressure range indicator 3
ssure is achieved.
Once the pressure is achieved the pressure range indicator 3 will be permanently on.
11.2.9 Micro-ClimateManagement(MCM)
The Microclimate Management (MCM) function starts to operate automatically when the SCU is turned on and a mattre-
ss is connected. The integrated MCM function is achieved by providing air through two dedicated manifolds running
the mattress air cells and the inside surface of the top cover to encourage moisture vapour transmission.
WARNING!
Riskofinjuryduetoincorrectpressuresetting!
CAUTION!
Riskofincompatibilityduetoincorrectbedsheet!
Use air-permeable bed sheet exclusively!
