Linksys LAPAC1750PRO User Manual

Section 2: Viewing Access Point System Status
LAPAC1750PRO Access Point Software User Manual
8
MAC Address Shows the MAC address of the AP. The address
shown here is the MAC address associated with the
management interface. This is the address by which
the AP is known externally to other networks.
Firmware Version Shows version information about the firmware
currently installed on the AP. As new versions of
the WLAN AP firmware become available, you can
upgrade the firmware on your AP.
Hardware Version Identifies the AP hardware version.
System Uptime Provides information about the system start up time.
Power Source The power source of monitor system is the power
adapter or PoE.
Connecting to the AP Web Interface
Using the IPv6 Address
To connect to the AP by using the IPv6 global address or IPv6 Link Local address,
you must enter the AP address into your browser in a special format.
NOTE:
The following instructions and examples work with Microsoft Internet
Explorer 7 (IE7) and might not work with other browsers.
To connect to an IPv6 global address, add square brackets around the IPv6
address. For example, if the AP global IPv6 address is 2520::230:abff:fe00:2420,
type the following address into the IE7 address field:
http://[2520::230:abff:fe00:2420].
To connect to the iPv6 Link Local address, replace the colons (:) with hyphens
(-), add the interface number, preceded by an “s,” then add “.ipv6-literal.net.”
For example, if the AP Link Local address is fe80::230:abff:fe00:2420, and the
Windows interface is defined as “%6,” type the following address into the IE7
address field: http://fe80--230-abff-fe00-2420s6.ipv6-literal.net.
Network Interfaces
This page displays the current settings for the wired Ethernet interface and the
wireless radio interfaces on the AP.
To monitor Ethernet LAN (wired) and wireless LAN (WLAN) settings, click the
System Status > Status and Statistics > Network Interfaces tab.
Figure 3: Viewing Network Interfaces
NOTE:
The information on this page is read-only. To change the wired or wireless
interface settings, click the Edit link associated with the appropriate
section.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
