Linksys LAPAC1750PRO User Manual

118
Section 4: Maintenance of the Access PointLAPAC1750PRO Access Point Software User Manual
In remote capture mode, traffic is sent to the PC running Wireshark via one
of the network interfaces. Depending on where the Wireshark tool is located
the traffic can be sent on an Ethernet interface or one of the radios. In order to
avoid a traffic flood caused by tracing the trace packets, the AP automatically
installs a capture filter to filter out all packets destined to the Wireshark
application. For example if the Wireshark IP port is configured to be 58000
then the following capture filter is automatically installed on the AP:
not portrange 58000-58004.
Enabling the packet capture feature impacts performance of the AP and can
create a security issue (unauthorized clients may be able to connect to the
AP and trace user data). The AP performance is negatively impacted even if
there is no active Wireshark session with the AP. The performance is negatively
impacted to a greater extent when packet capture is in progress.
Due to performance and security issues, the packet capture mode is not saved
in NVRAM on the AP; if the AP resets, the capture mode is disabled and then
you must re-enable it in order to resume capturing traffic. Packet capture
parameters (other than mode) are saved in NVRAM.
In order to minimize performance impact on the AP while traffic capture is in
progress, you should install capture filters to limit which traffic is sent to the
Wireshark tool. When capturing 802.11 traffic, a large portion of the captured
frames tends to be beacons (typically sent every 100ms by all Access Points).
Although Wireshark supports a display filter for beacon frames, it does not
support a capture filter to prevent the AP from forwarding captured beacon
packets to the Wireshark tool. In order to reduce performance impact of
capturing the 802.11 beacons, you can disable the capture beacons mode.
The remote packet capture facility is a standard feature of the Wireshark tool
for Windows.
NOTE:
Remote packet capture is not standard on the Linux version of Wireshark;
the Linux version doesn’t work with the AP.
Wireshark is an open source tool and is available for free; it can be downloaded
from http://www.wireshark.org.
Table 78 describes the fields to configure the packet capture status.
Table 78: Remote Packet Capture
Field Description
Remote Capture Port Specify the remote port to use as the destination
for packet captures. Default port is 2002. (Range
1025 to 65530).
Packet Capture File Download
Packet Capture File Download allows you to download the capture file
by TFTP to a configured TFTP server or by HTTP(S) to a PC. TFTP file name
should not contain spaces, <, >, |, \, /, : , (, ), &, ; , #, ? , *, $, % and successive
‘.’. The captured packets are stored in file /tmp/apcapture.pcap on the AP. A
capture is automatically stopped when the capture file download command
is triggered.
Because the capture file is located in the RAM file system, it disappears if the
AP is reset.
Diagnostic Log
The Diagnostic Log page provides a way to gather the diagnostic/
troubleshooting information about the AP beyond what is available through
the Web UI.
Table 79 describes the field of diagnostic log.
Table 79: Diagnostic Log
Field Description
Download To download the diagnostic information for support, click
Download button.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
