Section 4: Maintenance of the Access PointLAPAC1750PRO Access Point Software User Manual
Restoring Configuration
You can use HTTP or TFTP to transfer files to and from the access point. After
you download a configuration file to the management station, you can
manually edit the file, which is in XML format. Then, you can upload the edited
configuration file to apply those configuration settings to the AP.
Use the following procedures to restore the configuration on an AP to previously
saved settings by using TFTP:
1. Select TFTP for Upload Method.
2. Enter a name (1 to 256 characters) for the backup file in the Filename field,
including the .xml file name extension and the path to the directory that
contains the configuration file to upload.
NOTE:
File name should not contain spaces, < , > , | , \ , / , : , (, ), & , ; , # , ?, *, $, %, ‘,
“, and successive ‘.’ .
3. Enter the IP address of the TFTP server in the Server IP field.
4. Click the Restore button.
The AP will reboot. A reboot confirmation dialog and follow-on rebooting
status message will pop up. Please wait for the reboot process to complete,
which might take several minutes. The Administration Web UI is not
accessible until the AP has rebooted.
Use the following steps to save a copy of the current settings on an AP to a
backup configuration file by using HTTP:
1. Select HTTP for Upload Method.
2. Use the Browse button to select the file to restore.
3. Click the Restore button.
A File Upload or Choose File dialog box will pop up.
4. Navigate to the directory that contains the file, select the file to upload and
click Open.
(Only those files created with the Backup function and saved as .xml
backup configuration files are valid to use with Restore; for example, ap_
config.xml.)
5. Click the Restore button.
A dialog box will open asking you to verify the restore.
6. Click OK to proceed.
The AP will reboot. A reboot confirmation dialog and follow-on rebooting
status message will pop up. Please wait for the reboot process to complete,
which might take several minutes.
The Administration Web UI is not accessible until the AP has rebooted.
Reset/Reboot
• To Restore the Factory Default Configuration
If you are experiencing problems with the access point and have tried all other
troubleshooting measures, click Reset. This restores factory defaults and clears
all settings, including settings such as a new password or wireless settings.
• To Reboot the Access Point
For maintenance purposes or as a troubleshooting measure, you can reboot
the access point. To reboot the access point, click the Reboot button on the
Reset/Reboot page.
Diagnostics
This section include following subsections:
• Packet Capture
• Diagnostic Log

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
