Linksys LAPAC1750PRO User Manual

62
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Max. Burst
Length
The Max. Burst Length is an AP EDCA parameter and
only applies to traffic flowing from the AP to the client
station.
This value specifies (in milliseconds) the maximum
burst length allowed for packet bursts on the wireless
network. A packet burst is a collection of multiple
frames transmitted without header information. The
decreased overhead results in higher throughput and
better performance.
Valid values for maximum burst length are 0.0
through 999.
Wi-Fi Multimedia Settings
Wi-Fi Multimedia Wi-Fi Multimedia (WMM) is enabled by default. With
WMM enabled, QoS prioritization and coordination
of wireless medium access is on. With WMM enabled,
QoS settings on the access point control downstream
traffic flowing from the AP to client station (AP EDCA
parameters) and the upstream traffic flowing from
the station to the AP (station EDCA parameters).
Disabling WMM deactivates QoS control of station
EDCA parameters on upstream traffic flowing from
the station to the AP.
With WMM disabled, you can still set some parameters
on the downstream traffic flowing from the AP to the
client station (AP EDCA parameters).
To disable WMM extensions, click Disabled.
To enable WMM extensions, click Enabled.
Station EDCA Parameters
Queue Queues are defined for different types of data
transmitted from station-to-AP:
• Data 0 (Voice) — Highest priority queue, minimum
delay. Time-sensitive data such as VoIP and
streaming media are automatically sent to this
queue.
• Data 1(Video) — Highest priority queue, minimum
delay. Time-sensitive video data is automatically
sent to this queue.
• Data 2 (best effort) — Medium priority queue,
medium throughput and delay. Most traditional IP
data is sent to this queue.
• Data 3 (Background) — Lowest priority queue, high
throughput. Bulk data that requires maximum
throughput and is not time-sensitive is sent to this
queue (FTP data, for example).
AIFS
(Inter-Frame
Space)
Arbitration Inter-Frame Spacing (AIFS) specifies a wait
time for data frames. The wait time is measured in
slots. Valid values for AIFS are 1 through 255.
cwMin
(Minimum
Contention
Window)
This parameter is used by the algorithm that
determines the initial random backoff wait time
(window) for retry of a data transmission during
a period of contention for Unified Access Point
resources. The value specified here in the Minimum
Contention Window is the upper limit (in milliseconds)
of a range from which the initial random backoff wait
time will be determined. The first random number
generated will be a number between 0 and the
number specified here. If the first random backoff
wait time expires before the data frame is sent, a retry
counter is incremented and the random backoff value
(window) is doubled. Doubling will continue until the
size of the random backoff value reaches the number
defined in the Maximum Contention Window.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
