Linksys LAPAC1750PRO User Manual

64
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Virtual Access Point Settings describes the fields and configuration options on
the VAP page.
Table 43: RADIUS Server Settings
Field Description
RADIUS IP
Address
Type
Specify the IP version that the RADIUS server uses.
You can toggle between the address types to configure
IPv4 and IPv6 global RADIUS address settings, but the AP
contacts only the RADIUS server or servers for the address
type you select in this field.
RADIUS IP
Address
RADIUS
IPv6
Address
Enter the IPv4 or IPv6 address for the primary global RADIUS
server. By default, each VAP uses the global RADIUS settings
that you define for the AP at the top of the VAP page, see
“Virtual Access Point (VAP)”.
When the first wireless client tries to authenticate with the
AP, the AP sends an authentication request to the primary
server. If the primary server responds to the authentication
request, the AP continues to use this RADIUS server as the
primary server, and authentication requests are sent to the
address you specify.
If the IPv4 RADIUS IP Address Type option is selected in the
previous field, enter the IP address of the RADIUS server
that all VAPs use by default, for example 192.168.10.23. If
the IPv6 RADIUS IP Address Type option is selected, enter
the IPv6 address of the primary global RADIUS server, for
example 2001:0db8:1234::abcd.
RADIUS
IP or IPv6
Address
1–3
Enter up to three IPv4 or IPv6 addresses to use as the
backup RADIUS servers. The field label is RADIUS IP Address
when the IPv4 RADIUS IP Address Type option is selected
and RADIUS IPv6 Address when the IPv6 RADIUS IP Address
Type option is selected.
If authentication fails with the primary server, each
configured backup server is tried in sequence. The IPv4 or
IPv6 address must be valid in order for the AP to attempt to
contact the server.
RADIUS
Key
Enter the RADIUS key in the text box.
The RADIUS key is the shared secret key for the global
RADIUS server. You can use up to 63 standard alphanumeric
and special characters. The key is case sensitive, and you
must configure the same key on the AP and on your RADIUS
server. The text you enter will be displayed as “*” characters
to prevent others from seeing the RADIUS key as you type.
RADIUS
Key 1–3
Enter the RADIUS key associated with the configured
backup RADIUS servers. The server at RADIUS IP Address-1
uses RADIUS Key-1, RADIUS IP Address-2 uses RADIUS Key-
2, and so on.
Enable
RADIUS
Accounting
Select this option to track and measure the resources a
particular user has consumed such as system time, amount
of data transmitted and received, and so on.
If you enable RADIUS accounting, it is enabled for the
primary RADIUS server and all backup servers.
NOTE:
After you configure the VAP settings, you must click Save to apply the
changes.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
