Linksys LAPAC1750PRO User Manual

69
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Figure 38: ACL Table 46: ACL Configuration
Field Description
ACL
ACL Name Enter a name to identify the ACL. The name can
contain from 1–31 alphanumeric characters and the
following special characters: hyphen, underscore,
backslash and colon. Spaces are not allowed.
ACL Type Select the type of ACL to configure:
• IPv4
• IPv6
• MAC
IPv4 and IPv6 ACLs control access to network
resources based on Layer 3 and Layer 4 criteria. MAC
ACLs control access based on Layer 2 criteria.
ACL RULE SETTING
ACL Name and Type Select the ACL to configure with the new rule. The
list contains all ACLs added in the ACL Configuration
section.
Rule To configure a new rule to add to the selected ACL,
select New Rule. To add an existing rule to an ACL or
to modify a rule, select the rule number.
When an ACL has multiple rules, the rules are applied
to the packet or frame in the order in which you add
them to the ACL. There is an implicit deny all rule as
the final rule.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
