Linksys LAPN300 User Manual

SSID Settings Screen
Security
Select SSID
Select the desired SSID from the drop-down list.
Security Mode
Select the desired security method from the list.
Security Mode
• Disabled - No security. Anyone using the correct SSID can connect to your network.
• WEP - The 802.11b standard. Data is encrypted before transmission, but the encryption
system is not very strong.
• WPA2-Personal - This is a further development of WPA-PSK, and offers even greater
security, using the AES (Advanced Encryption Standard) method. This method,
sometimes called "Mixed Mode," allows clients to use either WPA-Personal (with TKIP) or
WPA2-Personal (with AES).
• WPA2-Enterprise - Requires a RADIUS Server on your LAN to provide the client
authentication according to the 802.1x standard. Data transmissions are encrypted using
the WPA2 standard.
If this option is selected:
o This access point must have a client login on the RADIUS Server.
o Each user must authenticate on the RADIUS Server. This is usually done using
digital certificates.
o Each user's wireless client must support 802.1x and provide the RADIUS
authentication data when required.
o All data transmission is encrypted using the WPA2 standard. Keys are
automatically generated, so no key input is required.
• RADIUS - RADIUS mode utilizes RADIUS server for authentication and dynamic WEP key
generation for data encryption.
29

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
