Linksys LAPN300 User Manual

Chapter 1 - -- Quick Start Guide
LAPN300
Package Contents
• Linksys Wireless Access Point
• Quick Start Guide
• Ethernet Cable
• AC Power Adapter
• CD with Documentation
• Mounting Bracket
• Mounting Kit
• Ceiling Mount Back Plate
• Drilling Layout Template
Physical Details
• LED—There is one LED for the device.
LED Color
Activity
Status
Green
Blinking
System is booting.
Solid
System is normal; no wireless device
connected.
Blue
Blinking
Software upgrade in process.
Solid
System is normal; at least one wireless
device connected.
Red Solid
Booting process or update failed; hard
reset or service required.
Ports and Button
• Power Port—Connect the AC power adapter to this port.
o NOTE: Use only the adapter that came with your access point.
• Ethernet Port—Connect a wired network device to this port. This port supports PoE (Power
over Ethernet) with a PoE switch or PoE injector. The maximum power consumption for
5

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
