Linksys LAPN300 User Manual

Security Settings - WPA/WPA2-Enterprise
This version of WPA2-Enterprise requires a RADIUS Server on your LAN to provide the client
authentication. Data transmissions are encrypted using either the WPA or WPA2 standard.
Figure 22: WPA/WPA2-Enterprise Wireless Security Screen
WPA/WPA2-Enterprise Screen
WPA/WPA2-Enterprise
Primary Server Enter the IP address of the RADIUS Server on your
network.
Primary Server Port Enter the port number used for connections to the
RADIUS Server. It is a value from 1 to 65534, and
default is 1812.
Primary Shared
Secret
Enter the key value to match the RADIUS Server. It
consists of 1 to 64 characters.
Backup Server The Backup Authentication Server will be used when
the Primary Authentication Server is not available.
Backup Server Port Enter the port number used for connections to the
Backup RADIUS Server. It is a value from 1 to 65534,
and default is 1812.
Backup Shared
Secret
Enter the key value to match the Backup RADIUS
Server. It consists of 1 to 64 characters.
WPA Algorithm The encryption method is TKIP or AES.
34

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
