Linksys LAPN300 User Manual

Scheduler
State
Current scheduler status of the SSID.
•
N/A
No scheduler is enabled on the SSID, or the SSID is
disabled by administrator.
•
Active
The SSID is enabled.
•
Inactive
The SSID is disabled.
WDS Root
Status Status of the WDS Root: Enabled or Disabled.
Local MAC MAC Address of the WDS Root.
Local SSID Name of the WDS Root.
VLAN List VLAN List of the WDS Root.
When the VLAN function is enabled, WDS Root only
receives packets in the VLAN list from WDS Stations.
Packets not in the list will be dropped.
WDS Station
Interface
The index of WDS Station.
Status Status of the WDS Station: Enabled or Disabled.
Local MAC
MAC Address of the WDS Root.
Remote SSID SSID of the destination access point which is on the other
end of the WDS link to which data is sent or handed-off and
from which data is received.
Remote MAC MAC Address of the destinatio
n access point which is on
the other end of the WDS link to which data is sent or
handed-off and from which data is received.
Connection
Status
Status of the WDS Station. It can be Disabled, Connected
or Not Connected.
67

Linksys LAPN300 Specifications

General

Color	multi, white
Wi-Fi Speed	300 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.08 pounds
