22
Site Survey
Site Survey gives a snapshot of all access points and wireless routers within range of the
extender.
Log in to the settings interface (see “ How to Access the Settings Interface” on page 17 ).
Click the
Wireless
tab. Click the
Site Survey
page.
Select —Click the button next to the wireless network name (SSID) in the
Select
column, and click Connect. For dual -band networks, be sure to connect to both
bands, 2.4 GHz and 5 GHz.
SSID —The names of neighboring wireless networks.
GHz —The radio band (in GHz) of the neighboring wireless networks
Signal Strength —The power of the wireless signal received : dot only = 25%, dot
+ one wav e = 50%, dot + two waves = 75%, dot + three waves = 100%. If no
waves are displayed, your extender is too far from the upstream access point or
the signal is blocked. Try to keep the signal streng th between 50% and 100%
for optimum performance.
Security —Th e mode of security in use by the neighboring wireless networks If a
network supports Wi -Fi Protected Setup, the Wi -Fi Protected Setup icon is also
displayed.
QoS (Quality of Service)
RE7000 supports WMM (Wi -Fi Multimedia), which enhances the quality of se rvice (QoS) on a
network . QoS prioritiz es data packets according to four trac classes : voice, video , best eort,
and background. We recommend keeping th
e default QoS settings .
