When a port is in multi-session mode and RADIUS-Assigned VLAN is enabled,
the device automatically adds the port as an untagged member of the VLAN
that is assigned by the RADIUS server during the authentication process.
The device classifies untagged packets to the assigned VLAN if the packets
originated from the devices or ports that are authenticated and authorized.
NOTE:
In multi-session mode, RADIUS VLAN assignment is only supported when
the device is in Layer 2 system mode.
When the RADIUS-Assigned VLAN feature is enabled, the host modes behave
as follows:
• Single-Host and Multi-Host Mode
Untagged traffic and tagged traffic belonging to the RADIUS-assigned
VLAN are bridged via this VLAN. All other traffic not belonging to
unauthenticated VLANs is discarded.
• Full Multi-Sessions Mode
Untagged traffic and tagged traffic not belonging to the unauthenticated
VLANs arriving from the client are assigned to the RADIUS-assigned VLAN
using TCAM rules and are bridged via the VLAN.
Common Tasks
Workflow 1: To enable 802.1x authentication on a port:
STEP 1 Click Configuration > Security > Network Access Control > Feature
Configuration.
STEP 2 Enable Port-based Authentication.
STEP 3 Select the Authentication Method.
STEP 4 Click Apply, and the Running Configuration file is updated.
STEP 5 Click Configuration > Security > Network Access Control > Port
Authentication.
STEP 6 Select the required port and click Edit.
STEP 7 Set the Host Authentication mode.
STEP 8 Select a port, and click Edit.
STEP 9 Set the Administrative Port Control field to Auto.
STEP 10 Define the authentication methods.
STEP 11 Click Apply, and the Running Configuration file is updated.
Workflow 2: To configure 802.1x-based authentication
STEP 1 Click Configuration > Security > Network Access Control > Port
Authentication.
STEP 2 Select the required port and click Edit.
STEP 3 Enter the fields required for the port.The fields in this page are
described in Port Authentication.
STEP 4 Click Apply, and the Running Configuration file is updated.
Workflow 3: To configure the guest VLAN:
STEP 1 Click Security > Network Access Control > Feature Configuration.
STEP 2 Select Enable in the Guest VLAN field.
STEP 3 Select the guest VLAN in the Guest VLAN ID field.
STEP 4 Click Apply, and the Running Configuration file is updated.
Feature Configuration
The Feature Configuration page is used to globally enable 802.1X and define
how ports are authenticated. For 802.1X to function, it must be activated
globally and individually on each port.
To define port-based authentication:
STEP 1 Click Configuration > Security > Network Access Control > Feature
Configuration.
STEP 2 Enter the parameters.
• Port-Based Authentication—Enable or disable port-based authentication.
If this is disabled 802.1X is disabled.
• Authentication Method—Select the user authentication methods. The
options are as follows:
• RADIUS, None—Perform port authentication first by using the
RADIUS server. If no response is received from RADIUS (for example,
if the server is down), then no authentication is performed, and the
session is permitted.
• RADIUS—Authenticate the user on the RADIUS server. If no
authentication is performed, the session is not permitted.
• None—Do not authenticate the user. Permit the session.
