Chapter 2: Getting to Know the PTZ Internet Camera
Camera Ports and Button
Wireless-G PTZ Internet Camera with Audio
Camera Ports and Button
The Camera features three ports and a Reset button on the bottom panel.
POWER The POWER port is where you will connect the power adapter.
MIC IN The MIC IN port is where you will connect the 3.5 mm input jack of your external microphone
(optional).
ETHERNET The ETHERNET port is where you will connect the Ethernet network cable.
RESET The RESET button is what you will press if you need to reset the Camera. Insert a paper clip
into the opening next to the Ethernet port. Then press the button and hold it in for five seconds.
Figure 2-2: Camera Ports
POWER RESETETHERNETMIC IN
IMPORTANT: Resetting the Camera will erase all of
your settings, such as encryption information, and
replace them with the factory defaults. Do not reset
the Camera if you want to retain these settings.
