3.2. Technical data
COMPACTCUT 401 E
max. cutting depth 320 mm / 13”
max. saw blade diameter 800 mm / 31.5”
Saw blade arbor 25.4 mm / 10”
Saw blade rpm 1400 1/min (RPM)
Left/right-hand cut yes
Drive motor Electric motor
Power (kW/HP) 7.5 kW
Power consumption 400 V / 14.1 A
Current type 3PH + N + PE
Operating weight 156 kg / 344 lbs
Dimensions (min.) L/W/H 990 / 580 / 850 mm ( 39” / 23” / 33”)
1340 mm
850 mm
990 mm 580 mm
680 mm
