35/48
6.8. Cutting special forms
Flush with the wall
Flush-with-wall flange
A separately available blade guard for sawing flush with a wall can be attached to the floor saw.
To this end, the normal drive pin on the saw flange must be replaced with a shorter pin.
• Shut off the drive motor and wait for all parts to come to a stop
• Remove the guard and blade
• Install the short version of the blade mount and drive pin
• Mount the flush-with-wall blade on the flange using countersunk screws
