CHAPTER 2: TECHNICAL DATA 2-2
ALPHA 538/552
1. CHARACTERISTICS
NOTE: Depending on the options, these technical data may vary. Please refer to the technical
data sheet.
3 meter 12 feet 4 meter
Weight
2450 lbs (1100 kg) 2550 lbs (1150 kg) 2650 lbs (1200 kg)
Dimensions
See Floor Plan, page 2-3
Minimum diameter
(profiled: on flats)
5 mm
(square: 4 mm)
(hex: 5 mm)
5 mm
(square: 4 mm)
(hex: 5 mm)
5 mm
(square: 4 mm)
(hex: 5 mm)
Maximum diameter
ALPHA 538: 42 mm
ALPHA 552: 52 mm
Minimum bar stock length
1000mm
Maximum bar stock length
3200 mm 3800 mm 4200 mm
Minimum remnant length 90 mm
Maximum remnant length
400 mm
Pneumatic pressure 5 bar
Air consumption
< 10 liter / loading cycle
Main electrical power
3x 208 – 480 V
50 Hz – 60 Hz
Max. 6A
Pushing force
Nominal: 464N
Max. electrical: 1160N (0,5 seconds) + 630N with mechanical booster
Maximum feed rate
>1m/min
Loading cycle
35 - 40 seconds
Hydraulic oil ISO 100 / 14 gallons ISO 100 / 14 gallons ISO 100 / 14 gallons
2. FLOOR PLAN
Left to right bar feeder (L to R) Right to left bar feeder (R to L)
Lathe
Lathe
