CHAPTER 3: SETTING INTO OPERATION 3-3
ALPHA 538/552
From this point on, the bar feeder is unpacked in the same way as when delivered on a pallet.
The ALPHA 538/552 bar feeder is always delivered as follows:
· A pusher and guiding elements set is mounted in the bar feeder (A). Depending on the purchase
order, other sets may be delivered in a separate box.
· The remote control (B) and the interface plug (C) are packaged in a separate box (D), with the
technical documentation and the accessories. (D).
Take out the parts and place them in an easily accessible area for mounting the bar feeder.
A
B
C
D
