CHAPTER 4: ELECTRICS
4-9
(b) Module 1
Designation Description
A Output Q2.0~Q2.3
B Input I3.0~I3.3
C Flexible ribbon cable connecting to expansion module
(c) Module 2
Designation Description
A Analog Signal Output (for servo drive control).
B Main power I/P terminal
