CHAPTER 7: GENERAL DESCRIPTION
ALPHA ST 320
7-7
8. REMNANT DRAWER
The bar feeder is equipped with a remnant drawer (Fig 7.11). It may be removed to empty it and slide it
back into position when the bar feeder is in operation.
Max remnant length: 400 mm / 15.748 in
Min remnant length: 50 mm / 1.968 in
Fig 7.10
